SPD mini — night vision & thermal
SPD1200D03
905 nm miniature DToF rangefinder module
Ranging envelope
0.2–≥1,200 m
Key parameters
- Ranging range
- 0.2–≥1,200 m
- Accuracy
- ±0.3 m (≤100 m)
- Frequency
- 2–15 Hz adaptive
- Interface
- UART, TTL 3.3 V
- Envelope
- 10.7 × 16.8 × 22 mm
- Mass
- On request
Published price
$130 USD / unit
Entry-band unit price at the smallest published quantity. Shipping and Incoterms are confirmed in the quotation.
A compact 905 nm module reaching ≥1,200 m building range from a 10.7 × 16.8 × 22 mm body, with 2–15 Hz adaptive output over UART-TTL for weight-sensitive night-vision and thermal integration.
Designed into
- Thermal imaging
- Night vision
- Civil UAVs
Emitter
905 nm
Verified specifications
Every figure below is published together with the condition it was measured under. Where the source states no condition, the column is left empty rather than filled in.
| Parameter | Value | Condition |
|---|---|---|
| Laser wavelength | 905 nm | Source technical table |
| Maximum range | ≥1,200 m | 70% refl. building target; visibility ≥6 km |
| Minimum range | 0.2 m | 90% refl. whiteboard |
| Ranging accuracy | ±0.3 m (≤100 m) · ±(0.4 + 0.006×D) m (>100 m) | Source technical table |
| Measurement frequency | 2–15 Hz adaptive | Adaptive · source technical table |
| Interface | UART, TTL 3.3 V | Source technical table |
| Supply voltage | 3.3–5 V | Source technical table |
| Dimensions | 10.7 × 16.8 × 22 mm | Source technical table |
| Weight | On request | Source technical table |
| Laser safety class | On request | Source technical table |
| Operating temperature | On request | Source technical table |
| Protection rating | On request | Source technical table |
Not published
No pin assignment is published for SPD1200D03. The interface is UART, TTL 3.3 V; request the interface control document and we send the pinout and protocol with it.
Request the ICDAdjacent models
