SPD1200D03

A compact 905 nm module reaching ≥1,200 m building range from a 10.7 × 16.8 × 22 mm body, with 2–15 Hz adaptive output over UART-TTL for weight-sensitive night-vision and thermal integration.

Max range: 0.2–≥1,200 m
Accuracy: ±0.3 m (≤100 m)
Weight: On request
Interface: UART, TTL 3.3 V

905 nm Class 1 · IEC 60825-1 Thermal imaging Night vision Civil UAVs

Request a quote Download datasheet (PDF)

SPEC / SHEET

SPD1200D03 · 905 nm

Technical specifications full sheet


Laser wavelength	905 nm
Maximum range	≥1,200 m (70% refl. building target; visibility ≥6 km)
Minimum range	0.2 m (90% refl. whiteboard)
Ranging accuracy	±0.3 m (≤100 m) · ±(0.4 + 0.006×D) m (>100 m)
Measurement frequency	2–15 Hz adaptive
Interface	UART, TTL 3.3 V
Supply voltage	3.3–5 V
Dimensions	10.7 × 16.8 × 22 mm
Weight	On request
Laser safety class	On request
Operating temperature	On request
Protection rating	On request

Application fit where it ships

Thermal imaging Night vision Civil UAVs

Data is transmitted as a standard 8-byte UART frame (0x55 0xAA header, function code, four data bytes, checksum); distance is returned as the value ×10 for a one-decimal reading. A PC configuration tool and standard command set are available for integration.
